Manley Bolt 3/8 2000 Material 1.500 Length Under Head-Pack of 4 (Compatible with Manley Rod 14024)
$100.99
Important excerpt from the ARP catalog regarding proper fastener installation: “The importance of tightening fasteners to their required preload cannot be emphasized enough. If a fastener is not preload cannot be emphasized enough. If a fastener is not tightened properly, the fastener will not apply the required preload on the application it is being used for and may become susceptible to failure. Conversely, if a fastener is over tightened and stretched too much, it becomes susceptible to failure by exceeding it’s maximum yield point.”
Underhead Length: 1.500 in. - Recommended Stretch (w/ ARP Lube): .0058-.0062 in. - Qty: 4
Manley Connecting Rod Bolt - Replacement Parts - Cap Screws 3/8" ARP 2000 - 1.500" UHL. For H-Beam Standard Weight, H-Lite Series and Pro Series I-Beam. Stretch .0058" to .0062" ARP2000 mat'l 55-65 w/oil 45-55 w/lube
- Premium ARP-manufactured rod bolts engineered for high clamp load and reliability
- Provides consistent preload when installed using recommended stretch method
- Precision thread rolling and heat treatment for maximum tensile strength
- Ideal for high-horsepower, high-RPM street and racing applications
The Manley Performance ARP 2000 connecting rod bolts are engineered for high-performance automotive applications, offering exceptional strength and reliability. Designed for high-horsepower, high-RPM street and racing engines, these bolts ensure optimal clamping force when installed correctly using the recommended stretch method. Precision thread rolling and heat treatment processes provide maximum tensile strength, making them suitable for demanding engine environments. Proper installation, including achieving the specified stretch of .0058 to .0062 inches with ARP Lube, is critical to prevent fastener failure and ensure consistent preload. These bolts are compatible with H-beam standard weight, H-lite, and Pro Series I-beam connecting rods, providing a dependable solution for engine builders seeking durability and performance.
Features:
- Premium ARP-manufactured rod bolts engineered for high clamp load and reliability
- Provides consistent preload when installed using recommended stretch method
- Precision thread rolling and heat treatment for maximum tensile strength
- Ideal for high-horsepower, high-RPM street and racing applications
