ICON 2024+ Toyota Tacoma 1.25in-3in Stage 3 Suspension System Tubular w/ Triple Rate Spring

ICON tubular upper control arm kit is designed to improve the overall performance of the new 2024-2025 Toyota Tacoma with corrected front-end geometry, built in additional caster, and improved suspension component clearance. Replacing the OE ball joint with the all-new, serviceable, and rebuildable ICON Delta Joint PRO allows for full bump and droop travel of the front suspension while eliminating bind. The rear triple-rate coil design provides a softer droop and ride rates with a firmer overload rate that combine to deliver on-road comfort with excellent bottoming resistance and superior off-road performance. ICON 2.0 Aluminum Series remote reservoir rear shocks provide improved cooling ability and utilize a vehicle-specific valving that balances the performance of the truck from front to rear. The ICON Vehicle Dynamics 2024-2025 Toyota Tacoma Stage 3 suspension system is an excellent choice for those drivers looking to enhance the capabilities of their pickup on the road as well as in the dirt. ICON Tacoma suspension systems are designed with maximum performance and the serious driver in mind. ICON'S primary focus is increased wheel travel and damping ability, translating into outstanding control and ride quality on and off-road. APPLICATION NOTE #206: This kit is configured for fitment on 4WD models. If installing onto a 2WD Toyota Tacoma, front differential drop kit part number 55160 is not needed and the other suspension system components can be purchased individually with full system functionality. 2WD specific kits are coming soon!

• Front differential drop provides better maximum operating angle for CV joints and maximizes available wheel travel on 4WD models
• UCAs feature the patented (U.S. Pat. 10,731,700) Delta Joint Pro with 90 degrees of total articulation
• Triple rate rear coil springs improve performance and ride quality while providing .5" of rear lift
• Tubular UCAs for added strength, durability, and alignment correction for better drivability
• Vehicle specific tuned front and rear shocks for superior shock damping and control
• Corrosion resistant CAD plated coilover shock bodies with 7/8" shafts
• FK Rod End bearings for extended longevity and minimal deflection
• 2.0 Aluminum Series remote reservoir rear shocks with 5/8" shafts
• Adjustable coilovers provide 1.25-3" front lift height over stock
• Increased wheel travel and improved ride quality over stock
• 6061 aircraft grade aluminum CNC machined components
• ICON engineered front and rear coil springs

Enhance your 2024-2025 Toyota Tacoma’s performance with the ICON Stage 3 suspension system, designed for serious off-road enthusiasts and daily drivers alike. This comprehensive kit features tubular upper control arms with patented Delta Joint PRO technology, providing 90 degrees of articulation for improved wheel travel and precise alignment. The system corrects front-end geometry, adds built-in caster, and improves suspension clearance, delivering superior handling and stability both on and off the pavement. The adjustable coilovers allow for a lift height ranging from 1.25 to 3 inches over stock, enabling customization for various driving conditions and preferences. Built with 6061 aircraft-grade aluminum CNC-machined components, these coilovers combine strength, durability, and lightweight performance. The inclusion of triple-rate coil springs in the rear provides a softer droop and ride comfort while maintaining a firm overload rate for excellent bottoming resistance and off-road capability. ICON’s vehicle-specific tuned shocks, including 2.0 Aluminum Series remote reservoir shocks with 5/8 inch shafts, offer enhanced cooling and damping control, ensuring consistent performance during demanding drives. The use of FK Rod End bearings minimizes deflection and extends component longevity, making this suspension system a reliable upgrade for your Tacoma. Designed specifically for 4WD models, the kit features a front differential drop for improved CV joint angles and maximum wheel travel. The system’s corrosion-resistant CAD plated shock bodies and high-quality materials ensure long-lasting performance in harsh environments. Whether tackling rugged trails or cruising city streets, the ICON Stage 3 suspension system provides increased wheel travel, improved ride quality, and superior control, making it an ideal upgrade for Tacoma owners seeking enhanced capabilities and durability.

Features:

• Front differential drop for improved CV joint angles and maximum wheel travel on 4WD models

• Patented Delta Joint PRO with 90 degrees of articulation for optimal front control

• Triple rate rear coil springs for improved ride quality and 0.5 inch of rear lift

• Tubular upper control arms for added strength, durability, and alignment correction

• Vehicle-specific tuned front and rear shocks for superior damping and handling

• Corrosion-resistant CAD plated shock bodies with 7/8 inch shafts for longevity

• FK Rod End bearings for extended durability and minimal deflection

• 2.0 Aluminum Series remote reservoir shocks with 5/8 inch shafts for cooling and control

• Adjustable coilovers providing 1.25 to 3 inches of front lift

• Increased wheel travel and improved ride comfort over stock components

• 6061 aircraft-grade aluminum CNC-machined parts for lightweight strength

• ICON engineered front and rear coil springs for optimal performance

Fitment:
Toyota Tacoma Limited 2024
Toyota Tacoma SR5 2024
Toyota Tacoma SR5 2025
Toyota Tacoma TRD Off-Road 2024
Toyota Tacoma TRD Off-Road 2025
Toyota Tacoma TRD Sport 2024
Toyota Tacoma TRD Sport 2025
