CSF 08-15 Mitsubishi Lancer Evo X Radiator

CSF has over 5 decades of experience manufacturing radiators. So when it comes to keeping your engine cool and your Evo X running at its best, a CSF High-Performance All-Aluminum Radiator is the obvious choice. Designed to perform on the street or at the track, a performance radiator is a must-have for both high horsepower builds as well as race vehicles which need added cooling performance in motorsports environments. This radiator features a 2-Row core with CSF's exclusive B-Tube Technology: Unlike a regular oval shape "O" type radiator tube, CSF uses a specially engineered tube in the shape of a "B". These "B-tubes" are carefully formed and then brazed over the seam to seal. CSF is able to use thinner and lighter aluminum material (with better cooling efficiency) because this design is actually stronger than normal "O" shape tubes that are welded. The design (inlet in the middle of the tube that is seam brazed) increases the heat transfer surface area of the tubes by approximately 15% over regular tubes - producing the efficiency of two smaller tubes vs. one large tube within the same space criteria. With "B-tubes" you are able to get "dual liquid laminar flow". CSF also uses ultra efficient multi louvered fins that are carefully and precisely aligned to maximize airflow through each radiator core. Fin specifications are carefully measured and calculated for each application, and tested for maximum heat rejection efficiency in our wind-tunnel lab. CSF manufactures the most advanced and efficient radiator in the industry for your Evo X. CSF uses innovative tube and fin technologies with industry-leading testing methods to maximize airflow and heat dissipation. The CSF #7019 Cooling product is designed to be a "Drop-In Fit" application. The product will install in the OEM Location with no modifications necessary unless otherwise noted or instructions are included in the product package. Please see the manufacturer repair manual for standard installation instructions. If you do not feel confident installing this product CSF recommends taking it to a qualified installation facility.

• "Drop-in Fit" Requiring No Modifications to Install - Accepts All Attaching OEM Components Including "Quick Connect" Hoses, AC Condenser, Mounting Brackets and Fan Shroud
• Core Features an Ultra-Efficient Fin with 6.5mm Fin Height and Multi-Louvered Design for Maximum Surface Area Contact
• 2-Row 42mm Core (Dual Core) Featuring CSF's Exclusive B-Tube Technology
• CNC Machined Brackets and Fittings for Superb Fit and Durability
• CNC Machined "Quick-Connect" Inlet/Outlet Connections
• All-Aluminum Race Style Drain Plug
• Smooth Satin Finish

The CSF #7019 High-Performance All-Aluminum Radiator is engineered to deliver exceptional cooling efficiency for your Mitsubishi Lancer Evo X. With over 50 years of manufacturing experience, CSF has developed a radiator designed to perform reliably on both street and track applications. Featuring a 2-Row core with CSF's exclusive B-Tube Technology, this radiator offers increased heat transfer surface area and improved durability. The B-tubes are carefully formed in a 'B' shape and brazed over the seam, allowing for thinner, lighter aluminum construction that enhances cooling performance while maintaining strength. This design provides approximately 15% more surface area compared to traditional oval tubes, promoting superior heat dissipation and dual liquid laminar flow for optimal cooling efficiency. The multi-louvered fins are precisely aligned and tested in wind-tunnel environments to maximize airflow and heat rejection, ensuring your engine stays cool under demanding conditions.
CSF manufactures this radiator as a direct drop-in replacement, requiring no modifications for installation. It accepts all OEM components, including quick-connect hoses, the AC condenser, mounting brackets, and fan shroud, making it suitable for a straightforward installation process. The core features a 6.5mm fin height with a multi-louvered design, providing maximum contact surface for heat transfer. CNC machined brackets and fittings guarantee a perfect fit and long-lasting durability, while the all-aluminum race-style drain plug allows for efficient maintenance. The radiator's smooth satin finish not only enhances its appearance but also offers corrosion resistance and easy cleaning, ensuring it remains in excellent condition over time.
Designed specifically for Mitsubishi Lancer Evo X models from 2010 to 2015, this radiator is an essential upgrade for high-performance builds, race vehicles, or anyone seeking improved engine cooling. Whether you're upgrading for racing or enhanced street performance, the CSF #7019 radiator provides industry-leading technology and craftsmanship to keep your engine running at its best. Installation is straightforward for those familiar with automotive upgrades, but CSF recommends professional installation if you're unsure about the process. Trust CSF's innovative engineering and proven performance to meet your cooling needs and ensure reliable operation in demanding environments.

Features:

• Drop-in Fit for seamless OEM component compatibility

• 2-Row 42mm core with CSF's exclusive B-Tube technology for enhanced heat transfer

• Ultra-efficient multi-louvered fins with 6.5mm fin height for maximum surface contact

• Accepts all OEM components including quick-connect hoses and mounting brackets

• CNC machined brackets and fittings for precise fit and durability

• All-aluminum construction with satin finish for corrosion resistance

• Includes a race-style aluminum drain plug for easy maintenance

Fitment:
Mitsubishi Lancer Evolution MR 2008
Mitsubishi Lancer Evolution MR 2010
Mitsubishi Lancer Evolution MR 2011
Mitsubishi Lancer Evolution MR 2012
Mitsubishi Lancer Evolution MR 2013
Mitsubishi Lancer Evolution MR 2015
